High pressure screw air compressor

Smart housekeeper remote monitoring, 24-hour online monitoring, no need for special management to open the phone to quickly obtain machine operation information. When the machine encounters a malfunction or needs maintenance, the system will automatically send an early warning message.

Next Product

Inquire Now

Product Details

Technical Parmeters

Catalogue Download

PARAMETERS AIRHORSE 4IN 1 TYPE PM VSD LASER MACHINE SCREW AIR COMPRESSOR
Model	Motor Power	Working Pressure	Air Flow	Outlet Diameter	Size	Weight
Model	(KW)	(Mpa)	(m3/min)	（inch/mm）	LxWxH(mm)	（KG）
BPM-20A	15	1.6	1.25	3/4"	17858401800	540
BPM-30A	22	1.6	1.84	3/4"	17858401800	600
PARAMETERS AIRHORSE SCREW AIR COMPRESSOR SPECIALLY FOR LASER MACHINE
Model	Motor Power	Working Pressure	Air Flow	Outlet Diameter	Size	Weight
Model	(KW)	(Mpa)	(m3/min)	（inch/mm）	LxWxH(mm)	(KG)
AHB-10A	7.5	1.6	0.48	1/2"	860x730x960	210
AHB-15A	11	1.6	0.65	3/4"	940x800x1075	260
AHB-20A	15	1.6	1.2	3/4"	940x800x1075	305
AHB-30A	22	1.6	1.75	1"	1200x950x1150	410
AHB-50A	37	1.6	3	1 1/2"	1500x990x1420	610
AHB-60A	45	1.6	4.3	1 1/2"	1500x990x1420	680
AHD-75A	55	1.6	5	1 1/2"	1500x990*1420	750
AHD-100A	75	1.6	6.4	2"	1800x1160x1490	870
AHD-120A	90	1.6	8.5	2"	1800x1160x1490	900
AHD-150A	110	1.6	10.7	2"	210014001780	1550
AHD-175A	132	1.6	14.5	2 1/2"	250014501800	2050
AHD-220A	160	1.6	18.2	2 1/2"	250014501800	2550

High pressure screw air compressor
Download

Why Choose Us ?

High Quality Control

AirHorse ensure every machine Runs well more than 15 years
Quickly Effect Shipment

Stock Available + Very Quickly Effect Shipment
24 Hours
Service

24 Hours Service Always at your service

AirHorse is an internationally renowned manufacturer of screw air compressors, please contact us for more information on air compressors. For a long time to provide you with high quality air compression services.
