Low pressure screw air compressor (3-5bar) |
|||||
| Model | Discharge pressure | Air flow | Dimension | Pipe diameter | Weight |
| （Mpa） | （m³/min） | （LxWxH）mm | （kg） | ||
| AHL-20HP | 0.3 | 3.8 | 1200*900*1150 | G 1 | 460 |
| 0.4 | 3.65 | ||||
| AHL-30HP | 0.3 | 5.8 | 1560*1000*1365 | G1 1/2 | 645 |
| 0.4 | 5.5 | ||||
| AHL-50HP | 0.3 | 10 | 1800*1160*1490 | G2 | 900 |
| 0.4 | 7.6 | ||||
| 0.5 | 7.3 | ||||
| AHL-60HP | 0.3 | 12.8 | 2100*1400*1780 | G2 | 1300 |
| 0.4 | 9.8 | 1800*1160*1490 | 940 | ||
| 0.5 | 9.6 | ||||
| AHL-75HP | 0.2 | 19 | 2700*1550*2100 | G2 1/2 | 2750 |
| 0.3 | 16 | 2100*1400*1780 | G2 | 1450 | |
| 0.4 | 12.5 | 1800*1160*1490 | 1100 | ||
| 0.5 | 12.3 | ||||
| AHL-100HP | 0.2 | 28.58 | 3100*1750*2250 | DN80 | 3050 |
| 0.3 | 20 | 2500*1450*1800 | G2 1/2 | 2050 | |
| 0.4 | 15.7 | 2100*1400*1780 | G2 | 1500 | |
| 0.5 | 15.4 | ||||
| AHL-120HP | 0.3 | 23 | 2700*1550*1800 | G2 1/2 | 2350 |
| 0.4 | 22.5 | ||||
| 0.5 | 19.3 | 2500*1450*1800 | 2150 | ||
| AHL-150HP | 0.3 | 28.6 | 2800x1550x1950 | DN80 | 3300 |
| 0.4 | 28.3 | ||||
| 0.5 | 22.2 | 2700*1550*1800 | G2 1/2 | 2650 | |
| AHL-175HP | 0.3 | 39 | 3700*2150*2250 | DN80 | 4700 |
| 0.4 | 31.1 | 2700*1550*1800 | G2 1/2 | 3150 | |
| 0.5 | 17.9 | ||||
| AHL-220HP | 0.3 | 43 | 3700*2150*2250 | DN80 | 4700 |
| 0.4 | 38.9 | ||||
| 0.5 | 31.4 | 2800x1550x1950 | 3450 | ||
| AHL-250HP | 0.3 | 43 | 3700*2150*2250 | DN80 | 5000 |
| 0.4 | 42.7 | ||||
| 0.5 | 38.9 | 3250*2100*2300 | 4050 | ||
