| Model | AHB-5A | AHB-7A | AHB-10A | AHB-15A | AHB-20A |
|---|---|---|---|---|---|
| Free Air Deliver / Discharge Pressure (m3/min/Mpa) | 0.55/0.8 |
0.85/0.7 0.75/0.8 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
| Free Air Deliver / Discharge Pressure (CFM/PSI) | 0.55/0.8 |
0.85/0.7 0.75/0.8 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
1.2/0.7 1.1/0.8 0.9/1.0 0.7/1.2 |
| Compression Stage | Single Stage | ||||
| Ambient Temprerature | -5~+45℃ | ||||
| Cooling Mode | Air Cooling | ||||
| Discharge Temperature (℃) | Ambient Temperature+15℃ | ||||
| Lubricant (L) | 3 | 3.7 | 3.7 | 10 | 10 |
| Noise Level (Db) | 62±2 | 64±2 | |||
| Drive Method | Belt Driven | ||||
| Electricity (V/ph/Hz) | 380 / 3 / 50 | ||||
| Motor Power (KW/HP) | 4 / 5.5 | 5.5 / 7.5 | 7.5 / 10 | 11 / 15 | 15 / 20 |
| Starting Method | Direct Starting | Y-△Starter (Star Delta Starting) | |||
AirHorse is an internationally renowned manufacturer of screw air compressors, please contact us for more information on air compressors. For a long time to provide you with high quality air compression services.
